Year: 2012
Design / surveying
- Master Plan
- Berthing capacity (490 boats)
- Main Breakwater (Rubble mound type, L=693m @max -6.50m MSL, 16m3 Accropodes blocks Type 1 Armor layer)
- Secondary Breakwater (Rubble mound type, L=111m @max -2.00m MSL with Rocky protection and L=280m @max -5.00m with 9m3/16m3 Accropodes blocks Type 1 Armor layer)
- RC crown wall
- Quaywalls (L=446m @-2.00m MSL) / Precast concrete blocks (Gravity QW)
- Quaywalls (L=222m @-4.50m MSL) / Precast concrete blocks (Gravity QW)
- Finger piers (Nbr=4; L=175m @-3.00m MSL) / Precast concrete blocks
- Finger piers (Nbr=2; L=112m @-4.50m MSL) / Precast concrete blocks
- 2 Water Outlets for basin flushing (Total L=109m)
- Slipway (Boat ramp)
- RC platforms (17,700m2)
- Asphalted platforms (7,700m2)
- Dredging works for quaywalls foundations and breakwater toe
- RC retaining sea walls
- Marine accessories (Mooring bollards, fenders)
- Infrastructure (Electrical supply, pipes, lighting poles)
- Infrastructure (Water supply, Pumps, pipes, tanks)
- Fishermen rooms (Nbr=30; 658m2)
- Rooms for Army, DGLMT and Ministry of agriculture (Nbr=3; 56m2)
- Fishermen syndicate building (204m2)
- Fish market (704m2)
- Waste water treatment plant
- Reclaimed area (68,500m2)
- Basin (31,220m2)
- Tender Documents / Drawings / BoQ
